OVERVIEW
Product description
SHOE-BOX-AREA-LIGHT
SHOE-BOX-AREA-LIGHT
SHOE-BOX-AREA-LIGHT2
SHOE-BOX-AREA-LIGHT2
SHOE-BOX-AREA-LIGHT3
SHOE-BOX-AREA-LIGHT3
TCL-LOGO
LED Shoe Box Area Light
Code No.
Product benefits

3 CCT and 3 Wattage selectable

Motion sensors and photocell sensors optional

IP 65 water-proof

UV resistant powder coat finish corrosion protection

Streamlined shape simple clean and stylish


PRODUCT DETAILS
TECHNICAL DATA AND BENEFITS
Features:

3 CCT and 3 Wattage selectable

Motion sensors and photocell sensors optional

IP 65 water-proof

UV resistant powder coat finish corrosion protection

Streamlined shape simple clean and stylish



CatalogueInput Voltage(V)Lamp Watt(W)EfficiencyLumen Output (Im)CCTDimmableCRI




Shoe Box Area Light

120-277V70W-100W-130W Selectable 135lm/W
9380lm&13400lm&20100lm3000k&4000k&5000k Selectable0-10V DIM80
120-277V100W-150W-200W Selectable 135lm/W13500lm&20250lm&27000lm3000k&4000k&5000k Selectable0-10V DIM80
120-277V150W-200W-240W Selectable 135lm/W20250lm&27000lm&32400lm3000k&4000k&5000k Selectable0-10V DIM80
120-277V200W-240W-300W Selectable 135lm/W26000lm&31200lm&39000lm3000k&4000k&5000k Selectable0-10V DIM80
